商品編號:SAM-80 8.5 GHz
SAM-80 8.5 GHz 即時頻譜
SAM-80 8.5 GHz Real-Time Spectrum Analyzer
SAM-80 8.5 GHz Real-Time Spectrum Analyzer 即時頻譜分析儀。
規格
SAM-80 8.5 GHz Real-Time Spectrum Analyzer

SAM-80 8.5 GHz Real-Time Spectrum Analyzer 即時頻譜分析儀

  • 9 kHz~8.5 GHz real-time spectrum analyzer
  • 100 kHz-6.3 analog signal generator (option)
  • 100 MHz analysis bandwidth, 300 GHz/sec spectrum sweep speed
  • FPGA based digital signal processing
  • 1 GHz Phase noise: -120 dBc/Hz @10kHz
  • 1GHz DANL: -169 dBm/Hz
  • Weight:168 grams (core module), size:142mm×54mm×16mm, power consumption:8-11 W
  • Highly compatible API interfaces and SAStudio4 GUI
  • Compatible with ARM and x86 processors, Linux and Windows operating systems
  • Operating temperatures range from -20 ℃/-40 ℃ to 65 ℃ (option)
  • Built-in OCXO (option), temperature drifting≤0.15 ppm
  • USB 3.0/2.0 Type-C interface

  • 9kHz至8.5 GHz 即時頻譜分析儀/接收器
  • 100 kHz至6.3/8.5 GHz 類比訊號源(選購)
  • 100MHz分析頻寬,300GHz/s掃速,FPGA訊號處理
  • 1GHz相位雜訊低至-120dBc/Hz @10kHz
  • 1GHz DANL低至-169dBm/Hz
  • 輕至168克(不含外殼),142x54x16mm,功耗8~11W
  • 使用新一代高相容性API介面(HTRA API)與SAStudio4應用程式
  • 支援ARM與x86處理器,支援linux與windows作業系統
  • 支援-20℃/-40℃至70℃工作溫度(選購品)
  • 內建OCXO(選購品),溫飄≤0.15ppm
  • USB3.0/2.0 Type-C 接口
