商品編號：TSBPF2425
TSBPF2425 Band Pass Filter
TSBPF2425 Band Pass Filter  2.4～2.5 GHz 帶通濾波器
規格
TSBPF2425 Band Pass Filter 2.4～2.5 GHz 帶通濾波器
Pass Band Frequency2.4～2.5 GHz
ConnectorSMA-Female
Impedance 50ohm
Insertion Loss≤0.6dB
Pass Band Ripple≤0.2dB
Return Loss≥23dB
Rejection


≥80dB @ DC ~ 2000MHz
≥75dB @ 2000 ~ 2100MHz
≥45dB @ 2100 ~ 2250MHz
≥45dB @ 2650 ~ 2800MHz
≥80dB @ 2800 ~ 8500MHz

Power Handling10W Max
Temperature Range-30℃ ~ +70℃
