商品編號：TSBPF2527
TSBPF2527 Band Pass Filter
TSBPF2527 Band Pass Filter  25 ~ 27 GHz 帶通濾波器
規格
TSBPF2527 Band Pass Filter 帶通濾波器
Pass Band Frequency25～27 GHz
Connector2.92mm-Female
Impedance 50ohm
Insertion Loss≤1.6dB
Pass Band Ripple≤0.55dB
Return Loss≥20dB
Rejection

≥80dB @ DC ~ 24630MHz
≥80dB @ 27700 ~ 44000MHz

Power Handling5W Max
Temperature Range-30℃ ~ +70℃
